Specifications
|
|
Fuel Type
|
Propane Gas
|
Natural Gas
|
|
Maximum Input and Minimum Input (Btuh/kW)
|
350,000 / 102.6 and 175,000 / 51.3
|
|
Inlet Gas Supply Pressure Acceptable at the Inlet of the Heater for Purpose of Input Adjustment (Inches W.C. / kPA)
|
MAX. 13.5 / 3.36
|
|
MIN. 11.0 / 2.74
|
MIN. 7.0 / 1.74
|
|
Burner Manifold Pressure (Inches W.C. / kPA)
|
HIGH HEAT 8.0 / 2.0
|
HIGH HEAT 3.5 / 0.87
|
|
LOW HEAT 2.0 / 0.49
|
LOW HEAT 0.8 / 0.20
|
|
Fuel Consumption Per Hour
|
16.2 lbs. / 7.34 kg
|
350 cu.ft. / 9.9 m^3
|
|
Motor Characteristics
|
Ball Bearing
|
|
1 H.P. / 745.7 Watts, 1,725 RPM
|
|
Blower Speed
|
915 RPM
|
|
Electrical Supply (Volts/Hz/Phase)
|
115 / 60 / 1
|
|
Amp Draw
|
Starting 35.0
|
|
Continuous Operation 11.0
|
|
Dimensions (Inches) L x W x H
|
48 x 22.25 x 32.75/122 x 56.5 x 83.2
|
|
Minimum Safe Distances From Nearest Combustible Materials
|
TOP 1 ft.
|
|
SIDES 1 ft.
|
|
BACK 1 ft.
|
|
BLOWER OUTLET 6 ft.
|
|
GAS SUPPLY Propane Gas - 6ft.
|
GAS SUPPLY Natural Gas - N/A
|
|
Net Weight
|
295 lbs.
|
|
Shipping Weight
|
310 lbs.
|
|
Minimum Ambient Temperature in Which Heater May Be Used
|
-20º F
|
